2KVA Fully Automatic Strapping Machine 45package/min 400kg

  • 1
  • 2

Brand Name : starpack

Model Number : SP-Y5

Certification : CE Certificate, Patent Certificate

Place of Origin : Guangzhou, CN

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 15 Sets per Month

Delivery Time : 30 days

Packaging Details : Steel Base with Carton and Film Wrapping

Name : Fully-automatic Strapping Machine

Voltage : 220V, 50/60 Hz, 1PH, 16 A CEE-plug

Automatic Type : Fully-automatic

Warranty : One Year

Service : Video Support,Online Support, Commissioning And Training

Type : PP Automatic Strapping Machine

Contact Now

Fully-automatic Strapping Machine with high Speed and easy to Operate and maintain

BRIEF INTRUCTION

Fully automatic Strapping Machine, one of post-printing equipment, is specially designed for packing finished products, which need to put into production for end-users. And it is well-pelleted by PP straps for transportation.

The standard model of fully automatic strapping machine have SP-Y5. Also can customized other size according to customer’s requirement.

MACHINE PHOTOS

2KVA Fully Automatic Strapping Machine 45package/min 400kg

TECHNICAL DATA

1 Machine Dimension
Installation length 850mm
Working Height 850 – 950 mm (adjustable)
2 Capacity(at table belt speed of 0.6m/s):
40-45 packages / minute for single strapping;
3 Strapping:
Standard machine grade 5mm PP straps, the thickness is about 0.47 mm
4 Strap Coil Dispenser:
Core Diameter: 200mm
Core Width: 190mm
5 Table load capacity:
20kg
6 Electrical Power:
Voltage: 220V, 50/60 Hz, 1PH, 16 A CEE-plug
Power Consumption: 2 KVA
7 Pheumatic
Operating Pressure:0.6-0.9 MP, 1M3/min.
8 Frame Size:
1250x500mm
9 Weight:
400kg

FEATURES

  1. Cartons transferred by rolling wheel.
  2. Energy-saving and wear-free direct drive DC sealer.
  3. Robust construction with new unibody sheet metal cabinetry.
  4. Easy strap coil change.
  5. When strap coil is depleted, remaining strap is automatically ejected out of machine.
  6. Large accumulator capacity ideal for bulk-bin applications.
  7. Roller conveyors swing wide open for easy sealer access.
  8. Forms and ejects strap loops if accidentally cycled without a bundle. Avoids jamming.
  9. Precision single piece strap track for positive control and exceptional feed reliability.
  10. Heavy duty casters, two lockable.
  11. Double full-width pneumatic compression bars for bundle stability during strapping operation.
  12. Control system using ARM system.
  13. Using automatic wear belt system.
  14. Adjust touch screen control system configuration.
  15. Operating parts are: the total power switch, permed hair light, M5 electrical switch.
  16. Welding and cooling time can adjust the touch screen.

MACHINE PHOTOS

2KVA Fully Automatic Strapping Machine 45package/min 400kg

ADVANTAGES

  1. High capability: Maximum output up to 40-45 pcs per min.
  2. Labor saving: 1 workers
  3. Easy Job: Order changing by 2 min. No need training.
  4. Wide range application: Be used to agriculture, food, logistics and industrial packaging.
  5. Acceptability in Precision: Pass rate is more than 99%
